| Model | Parameter | |
| Processor | CPU | Intel 8-9th Generation Core i3/5/7/9, Pentium, Celeron Processors, LGA1151 |
| Chipset | Intel® H310, TDP 6W | |
| BIOS | AMI UEFI BIOS (Support Watchdog Timer) | |
| Memory | Socket | Support DDR4-2400MHz,2×U-DIMM Slot |
| Max Capacity | Up to 32 GB | |
| Graphics | Controller | Intel® UHD Graphics |
| Ethernet | Controller | 2×Realtek GbE LAN Chip (10/100/1000Mbps) |
| Storage | SATA | 2×SATA 3.0 Port |
| MSATA | 1×Mini PCI-E (mSATA) | |
| Expansion Slots | PCIe | 1×PCI-E X16 slot |
| Mini PCIe | 1×Mini PCI-E Slot (WIFI+4G) | |
| GPIO | 8×GPIO | |
| Front I/O | Ethernet | 2×RJ45 |
| USB | 4×USB3.0(Type-A) | |
| 6×USB2.0(Type-A) | ||
| PS/2 | 1×PS/2(Keyboard & Mouse) | |
| Display | 1×VGA | |
| 1×HDMI 1.4 | ||
| Audio | Line-out + MIC 3.5mm Jack | |
| Serial | 4×RS232 | |
| Rear I/O | USB | 2×USB2.0(Type-A) |
| Button | 1×Power Button, 1×Reset Button | |
| LED | 1×Power status LED, 1×Hard drive status LED | |
| OS Support | Windows | Windows 10(64 bit) |
| Linux | Ubuntu | |
| Power Supply | Type | 1U FLEX |
| Power Input Voltage | AC power supply | |
| Environment | Operating Temperature | 0~60℃ |
| Storage Temperature | -20~75℃ | |
| Mechanical | Enclosure Material | SGCC+AL6061 |
| Dimensions | 482.6mm(L) ×283mm(W) ×44.5mm(H) | |
| Mounting | Rack-mounted/Desktop |
Preliminary Ordering Information
| Part No. | Description |
| IPC100-H110 | 1U Rackmount Industrial PC, Intel 6-7th Generation Core, Pentium, Celeron Processors, LGA1151 |
| IPC100-H310 | 1U Rackmount Industrial PC, Intel 8-9th Generation Core i3/5/7/9, Pentium, Celeron Processors, LGA1151 |
